AOS INSTALLATIONS
AOS LA 8.3
1x 8” LF, 1x 8” MF, 2x 1.7” HF, NEODYMIUM, 65 Hz – 18 KHz ±3 dB, 520W AES 132dB (PASSIVE)
AOS SP 15.3
1x 15” LF, 1x 6.5” MF, 1x 1.7” HF, NEODYMIUM, 40 Hz – 20 KHz ±3 dB, 700W AES 136dB (PASSIVE)
AOS SP i12.2
1x 12” LF, 1x 1.4” HF, NEODYMIUM, 50 Hz – 20 KHz ±3 dB, 450W AES 132dB (ACTIVE DSP)
AOS P8
1x 8” LF, 2x 1” HF, NEODYMIUM, 60 Hz – 20 KHz ±3 dB, 80W AES 112dB (PASSIVE 8Ω + 100V)
AOS P6
1x 6.5” LF, 1x 1” HF, NEODYMIUM, 70 Hz – 20 KHz ±3 dB, 40W AES 106dB (PASSIVE 8Ω + 100V)
AOS P4
1x 4” LF, 1x 1” HF, NEODYMIUM, 90 Hz – 20 KHz ±3 dB, 20W AES 102dB (PASSIVE 8Ω + 100V)
AOS C6
1x 6.5” LF, 1x 0.75” HF, NEODYMIUM, 60 Hz – 25 KHz ±3 dB, 60W AES 110dB (PASSIVE 8Ω + 100V)
AOS SUB i2.21
2x 21” LF, NEODYMIUM, 28 Hz – 120 Hz ±3 dB, 3600W AES 151dB (ACTIVE DSP)
AOS SUB i2.18
2x 18” LF, NEODYMIUM, 25 Hz – 140 Hz ±3 dB, 2000W AES 142dB (ACTIVE DSP)
AOS SUB 2.18
2x 18” LF, NEODYMIUM, 2×8Ω, 25 Hz – 180 Hz ±3 dB, 2x 1000W AES 142dB (PASSIVE)
AOS SUB i1.18
1x 18” LF, NEODYMIUM, 35 Hz – 140 Hz ±3 dB, 800W AES 132dB (ACTIVE DSP)
AOS S4.30 DSP
Number of Channels: 4
Output per Channel: 3000W @ 8Ω, 5000W @ 4Ω, 6500W @ 2Ω
CLASS D, Sesnitivity 32dB,35dB,38dB,41dB
Dynamic Energy Recycling
THD: 0.03%, DF: 5000, CH. PEAK Vp: 180V, BRIDGE PEAK Vp: 370V
Total Power: 2x 13000w @ 4Ω
(DANTE Optional)
AOS S4.15 DSP
Number of Channels: 4
Output per Channel: 1500W @ 8Ω, 2500W @ 4Ω, 3000W @ 2Ω
CLASS D, Sesnitivity 32dB,35dB,38dB,41dB
Dynamic Energy Recycling
THD: 0.03%, DF: 5000, CH. PEAK Vp: 180V, BRIDGE PEAK Vp: 370V
Total Power: 2x 6000w @ 4Ω
(DANTE Optional)
AOS S2.45 DSP
Number of Channels: 2
Output per Channel: 4500W @ 8Ω, 8200W @ 4Ω, 8600W @ 2Ω
CLASS D, Sesnitivity 32dB,35dB,38dB,41dB
Dynamic Energy Recycling
THD: 0.03%, DF: 5000, CH. PEAK Vp: 180V, BRIDGE PEAK Vp: 370V
Total Power: 17200w @ 4Ω
(DANTE Optional)
AOS A4 600
Number of Channels: 4
Output per Channel: 600W @ 8Ω, 900W @ 4Ω
CLASS D, Sesnitivity 32dB
THD: 0.03%, DF: 600
Total Power: 2x 2200w @ 4Ω
AOS DSP L48 FiR
Number of Inputs: 4 Analog
Number of Outputs: 8 Analog
THD+N 0.005%: 10Hz～25kHz
Max In/Out Level: 20dBu (7.75 Vrms)
Dynamic Range: 118dB
Sampling Rate: 196khz, 24bit
Functions: Limiter (RMS/PEAK), Compressor, Crossover, Delay, PEQ, Noise Gate, Feedback Remover, Signal Generator
PEQ Function: 7-Bands input / 15 bands Output
FIR + IIR Filter Support
High Pass/Low Pass, Phase, Bessel, Butterworth, Linkwitz-Riley 6dB/oct ~ 48dB/oct
WIFI Network Control & RS485
AOS DSP A48
Number of Inputs: 4 Analog
Number of Outputs: 8 Analog
THD+N 0.0035%: 20Hz～20kHz @ +4dBu
Max In/Out Level: 18dBu
Dynamic Range: 114dB
Sampling Rate: 48khz, 24bit
Functions: Limiter, Crossover, Delay, PEQ, Noise Gate, Feedback Remover, Pink Noise
PEQ Function: 16-band All inputs/outputs
IIR Filter Support
High Pass/Low Pass, Bessel, Butterworth, Linkwitz-Riley 6dB/oct ~ 48dB/oct
Network Control
